AudioMute

Bool

Whether to mute all audio on the player (global). This custom setting is available directly in the Audio setting.

Lite, Premium

false

1

AudioVolume

Integer

Set the player's audio volume (global) to the specified percent value. 100 equals 100% in Windows. This custom setting is available directly in the Audio setting.

Lite, Premium

No value = Use system volume

50

AudioVolumeSchedule

String

Comma separated list of volumes over a 24 hour period (start at 00.00)

Premium

No value = Use system volume

0,0,0,0,0,0,50,50,50,50,50,50,50,50,50,100,70,70,50,50,0,0,0,0

• Audio.VolumeSchedule.Sunday

• Audio.VolumeSchedule.Monday

• Audio.VolumeSchedule.Tuesday

• Audio.VolumeSchedule.Wednesday

• Audio.VolumeSchedule.Thursday

• Audio.VolumeSchedule.Friday

• Audio.VolumeSchedule.Saturday

String

Same as above, but for each day of the week. If not specific or day not specified will fall back to AudioVolumeSchedule

Premium

No value = AudioVolumeSchedule

0,0,0,0,0,0,50,50,50,50,50,50,50,50,50,100,70,70,50,50,0,0,0,0

ContentCachePath

String

Force use of alternative path for downloaded content. If the setting doesn't exist DISE will default to the best suitable drive.

Premium

No default

E:\MyContent

DownloadSchedule

String

Time of day when player is allowed to download content. Options: AlwaysOn (00:00 to 00:00), outsideBusinessHours (22:00 to 06:00), atNight (00:00 to 04:00).

Premium, Lite

 No default

Interlaced

Bool

If active, playback will use Interlaced mode in Direct3D.

Premium

false

1

UseDirect3D9Ex

Bool

Change Direct3D9 Extended usage. Will change behavior of graphic card memory sharing and screen change detection (default is defined in DISEGlobal.settings, usually 1/true)

Premium

Usually true

1

LogLevel

Integer

Log level to use. Emergency = 0, Alert = 1, Critical = 2, Error = 3, Warning = 4, Notice = 5, Info = 6, Debug = 7.

Premium, Lite

 No default

7

Network.Multicast.Enabled

Bool

Enables multicast (1 = enabled)

Premium

false

1

Network.UDP.Enabled

Bool

Enables UDP (1 = enabled)

Premium

false

1

Network.UDP.Port

Integer

Assign port for UDP

Premium

1515

RemoteControlEnabled

Bool

Enable remote control.

Premium

false

1

WebServerEnabled

Bool

Enable HTTP REST API in Replay.

Premium

1

WebServerPort

Integer

Port for HTTP REST API

Premium

8080

Debug

Bool

Show the output in windowed mode and without Always on top.

Lite, Premium

1

DirectMovieSceneScheduleChange

Bool

Apply schedule changes as directly as possible without finishing the currently playing cache.

Premium

1

DisablePlaybackStatistics

Bool

Disable sending statistics to server.

Premium

false

1

DisplayScheme

String

Force use of alternative display scheme (with extension .displayscheme). If no path is included in the filename it will look in the default download directory.

Premium

Player2.displayscheme

ExclusivePlayback

Bool

If active, playback will be done in Exclusive Direct3D mode.

Premium

true

0

KeepImageVideoLoaded

Bool

Never remove images/video from cache.

Premium

false

1

KeepWebPagesLoaded

Bool

Never remove web pages from cache.

Premium

false

1

LedMode

Bool

Run in windowed mode, always on top. Combine with ScreenWidth/ScreenHeight and ScreenX/ScreenY settings (see below).

Premium

1

Playback.DateOverride

String

Used to test scheduling, write the date you wish to lock scheduling to. In the format YYYY-MM-DD HH:MM:SS.

Premium

No value = off

2019-04-24 09:44:00

Playback.DestroyDataWaitSeconds

Integer

Number to seconds to keep resources loaded in the cache before unloading. For content low in size this value can be high and for large content it should be kept low to avoid running out of system or graphic memory.

Premium

30

30

Playback.Resources.KeepLoaded

Bool

Never remove resources from cache.
Introduced in v1.8.28

Premium

false

1

PlaybackSpeed

Integer

Speed up the playback for debug purposes

Premium

5

PreloadCacheDepth

Integer

Set number of scenes to preload in Replay

Premium

3

10

RestartPlaybackOnDisplayChange

Bool

If active, playback will be restarted if a change of display is detected.

Premium

false

0

ScreensaverMode

Bool

If the playback should only be active when the computer is idle.

Premium

false

1

ScreensaverDelay

Integer

The amount of idle time in seconds to wait before activating the playback.

Premium

30

Playback.Screensaver.TriggerName

String

if the trigger name is assigned to a channel, that channel will be defined as a screensaver, which means clicking or tapping on this channel will make this channel to be hidden

Lite (v30+)

TestScreen

Bool

Show test screen. Default is false.

Premium

false

1

Viewer

String

Determines what viewer version to use for playback.
Available values are:

• replay

• presentationviewer

Replay is the legacy viewer.

Premium

PresentationViewer

replay

Playback.Web.Endless

Bool

stop refresh for single web page

Lite player (v30+)

1

Probe.DestinationDirectory

String

Directory where Probe will download to (if used)

Premium with Probe

No value = Probe default (DISE Global settings)

Probe.DownloadInterval

Integer

Content download interval in seconds

Premium with Probe

No value = Probe default (DISE Global settings)

3600

Probe.DownloadSchedule

String

Download schedule for Probe.
Made from Copy all in Bridge schedule dialog and then Base64 encoded.

Premium with Probe

No value = No download schedule

Probe.Site

String

Additional sites for Probe to use

Premium with Probe

Base64 encoded FTP Sites settings to be used for Probe. Copy the FTPSite {...} part from Probe.settings

Control Probe Passive/Active FTP. Values accepted are Active and Passive.

Premium with Probe

active

ForceScreenState

Integer

0 = auto, 1 = on, 2 = off.
Force power state of screen.

Premium

0

0

Screen.AdditionalURIs

String

Comma separated list of URIs for additional screens connected using TCP or RS-232. For each entry a new screen service will be created. The following URI formats are supported:

tcp://ip:port

rs232://comport:screenid

These additional screens will use the same settings as the main screen.

Premium (v30+)

No value = No additional screens

tcp://1.2.3.4:1234,tcp://2.3.4.5:5678

rs232://com1:2,rs232://com2:3

ScreenAdapter

Integer

Index of screen to show on.

Premium

0 (first screen)

1

ScreenBrightness

Integer

Percentage brightness on screen (0-100). Not supported on all models.

Premium, Lite (WebOs, SSSP)

No value = Screen configuration

50

ScreenBacklight

Integer

Percentage backlight on screen (0-100). Not supported on all models.

Lite (SSSP)

No value = Screen configuration

85

ScreenContrast

Integer

Percentage contrast on screen (0-100). Not supported on all models.

Premium, Lite (WebOs, SSSP)

No value = Screen configuration

50

ScreenColor

Integer

Percentage color on screen (0-100). Not supported on all models.

Premium, Lite (WebOs)

No value = Screen configuration

50

ScreenId

Integer

Id of screen to control from player.

Premium

No value = All screens

2

ScreenInput

String

Input to use of screen. Not supported on all models.

Premium

No value = Screen selected input

ScreenMAC

String

To allow Wake On Lan for Screen. MAC Address of screen.

Premium

00-14-22-01-23-45

ScreenRotation

Int

Way of rotating the output screen content (0=No rotate, 1=90 deg. left, 2=180 deg, 3= 90 deg. right (270 deg))

Premium

0

3

Screen.Script

String

A Base64-encoded script which is run every minute to query and report the screen status.

See this article for more information: Screen script

Premium (v30+)

No value = Use normal RS232/TCP screen control.

ScreenSharpness

Integer

Percentage sharpness on screen (0-100). Not supported on all models.

Premium, Lite (WebOs, SSSP4+)

No value = Screen configuration

50

ShowMouseCursor

Bool

Show the mouse cursor (for instance for interactive presentations)

Lite (ChromeOS, v30+)
Premium

false

1

SimulateScreenControl

Bool

Simulate the communication with the screen, for debug.

Premium

false

1

WOLBroadcast

String

To allow WOL (Wake On Lan) for screen. WOL Broadcast IP.

Premium

192.168.0.255

SyncMode

String

Master or Slave. This will enable synchronization through multicast so it is important that players in sync are on the same subnet.

Premium

““

Master

• Network.Multicast.IP

• MulticastIp

String

The multicast IP to use for synchronization.

Premium

224.1.1.124

• Network.Multicast.Port

• MulticastPort

Integer

The multicast IP port to use for synchronization.

Premium

4001

Sync.Enabled

Bool

Enable sync mode for video display on SSSP4+ devices

Lite SSSP4+ (v31)

false

true

Sync.GroupId

Integer

Only screens with the same groupId will be synced if Sync.Enabled is set to true.

Lite SSSP4+ (v31)

5

23

RebootComputerAt

Integer

Reboot the computer at specified hour every day (1 = 1 AM, 13 = 1 PM)

Premium

4

RestartReplayAt

Integer

Restart Replay at specified hour (24 hour-based, all days).

-1 to disable.

Will use the time zone locally on the player.

Premium, Lite

-1 (disabled)

Lite defaults to 04.

6

SimulateHardwareControl

Bool

Simulate the communication with hardware, for debug.

Premium

false

0

TimeZoneOffset

Integer

Time zone offset in minutes from UTC

Premium

560

Var-X

String

Set a variable by the name "X" to the value denoted by value.

Premium, Lite (v30+)

value

VariableDefaultScope

String

Set default Variable scope. If set to "local" to force all variable reads to try local (movie context) source first.

If set to "global" local will not be tried unless specified.

Premium

local

local

UseInternalRenderer

Bool

Default is "VMR9", enable to use "Internal" instead.

Premium

false (VMR9)

1

Video.UseAVPlay

Bool

Enable to use the SSSP AVplayer instead of the video Tag.

Lite (Tizen, SSSP4+)

false

1

Video.UseCordovaPlayer

Bool

Enable to use the cordova plugin video player instead of the video Tag

Lite (Android)

false

1

Lite (SSSP4, SSSP6)

Samsung = disabled
